Type & Status
+
|
Type No. |
Status |
|
Monel 400 |
Sofe (M) Hard (Y) |
Size & Tolerance (mm)
+
|
Diameter |
Tolerance |
|
0.10-0.22 |
±0.005 |
|
0.22-0.37 |
±0.01 |
|
0.37-0.50 |
±0.015 |
|
0.50-1.0 |
±0.020 |
|
5.5-6.0 |
±0.05 |
Chemical Properties
+
|
Type No. |
Composition (%) |
||||||
|
|
Ni+Co |
Cu |
Fe |
Mn |
C |
Si |
Ti |
|
Monel 400 |
rest |
29-33 |
0.8-2.0 |
0.8-1.5 |
≦0.15 |
≦0.3 |
≦0.1 |
Physical Properties
+
|
Type No. |
Diameter (mm) |
Tensile strength (N/m ㎡) |
Extensibility |
||
|
|
|
M |
Y |
M |
Y |
|
Monel 400 |
﹥0.10-0.22 |
450-550 |
650-880 |
15 |
---- |
|
|
﹥0.22-0.50 |
440-550 |
650-880 |
20 |
---- |
|
|
﹥0.50-1.00 |
440-550 |
650-880 |
25 |
---- |
OEM is acceptable
